RICO G-LRF 640 3X 50mm Thermal Weapon Sight

MSRP $5,499.00
SKU: GH50R
UPC: 850029093725
Datasheet: Download
Manual: Download
Sensor Pixel Size: 12μm
Sensor Frame Rate: 50hz
Detection Range: 2400 Yards
Optical Magnification: 3X
Device Technology: Thermal Imaging
Sensor Resolution: 640×512
Objective Focal Length: 50mm
Digital Magnification: 4X, stepped
Onboard Recording: Yes
Objective F#: 1.1
Objective Diameter: 50mm

The InfiRay Outdoor RICO G-LRF Series introduces the next generation of thermal functionality,seamlessly combining InfiRay’s industry-leading 12 μm detector technology and a precision laserrange-finding module in a single unit. The RICO G-LRF Series features a 1024×768 AMOLED display toguarantee a crisp, high-contrast image, while the precision laser range-finding module ensures accuratemeasurement to 1000 yards. Additional features include image and video capture with 32GB of storage,wireless streaming, and a field-swappable 26650 battery with a 7-hour run-time.



  • Laser Specifications

  • Optics

    Detection Range

    2400 Yards

    Optical Magnification

    3X

    Objective Focal Length

    50mm

    Objective Lens Material

    Germanium

    Digital Magnification

    4X, stepped

    Focusing Mechanism

    Manual Focus

    Display Type

    AMOLED

    Vertical Angular Field of View

    6.6°

    Horizontal Angular Field of View

    8.8°

    Objective F#

    1.1

    Objective Diameter

    50mm

    Eye Relief

    48mm

    Diopter Range

    -4 - +4

    Display Resolution

    1024×768

  • Features & Performance

    Wifi

    Yes

    Image Capture

    Yes

    Mobile App

    Yes

    Connector Type

    USB-C

    Video Output

    Analog RS-170/NTSC

    Connector Output

    Power/Data

    Onboard Recording

    Yes

    Warranty

    5 Years

    Power Source

    26650 Battery

    Color Palettes

    White Hot, Black Hot, Red Hot, Color, Highlight

    Rangefinder

    Internal LRF

    Picture-in-Picture

    Yes

    User-Updatable Firmware

    Yes

    Storage Capacity

    32GB

    Startup Time

    Under 10 Seconds

    Run Time

    7

    One-Shot Zero

    Yes

    Stand-by Mode

    Yes

    Reticle

    7 (2 Dynamic, 5 Static)

    External Power Source

    USB-C

    Country of Manufacture

    China

  • Environmental Specifications

    Recoil Rating

    1000 g/s² (300 Win./7mm Mag)

    Operating Temperature Range

    -4°F~122°F

    Ingress Protection

    IP67

  • Physical

    Mounting Interface

    Picatinny STD-1913 rail

    Length

    8.85

    Width

    3.93

    Height

    2.42

    Weight

    25.71

    Housing Material

    Polymer

  • Sensor Specifications

    Sensor Type

    InfiRay MICRO II

    Sensor Pixel Size

    12μm

    Thermal Sensitivity

    <50mk

    Non-Uniformity Correction (NUC)

    Manual, Automatic, Semi-Automatic

    Spectral Response

    8-12 Microns

    Sensor Frame Rate

    50hz

    Device Technology

    Thermal Imaging

    Sensor Resolution

    640×512
